Rafter Roll

Designed to maintain ventilation between insulation and roofing felt to prevent the build-up of condensation. Suitable for new build and refurbishment work.

Use:

    • For pitched roof eaves ventilation
    • On standard pitched roofs where the pitch is 15 degrees or more and the roof void is an attic or loft space
    • On roofs with rafter spacings of between 400mm and 600mm centres

Add this product to your specification on NBS or SpecifiedBy

How To Order Full Datasheet

BIM Objects

We have partnered with the BIMstore to help provide you with the highest standard of BIM content around.

Browse BIM Information

Product Information

Roofline Roll Form Eaves Vent Roll Out Rafter Tray

Depth of ventilation channelWidthLengthProduct Code
>25mm300mm6m1121
>25mm400mm6m1171
>25mm600mm6m1131
>25mm800mm6m1151

  • Durable, totally resistant to decay, easy to fit
  • Supplied in convenient 6m rolls
  • Suitable for new build and refurbishment projects
  • Satisfies all NHBC requirements
  • Manufactured to BS EN ISO 9001 and BS IN ISO 14001
  • Complies with all relevant Building Regulations
  • Meets all relevant British Standards
  • Manufactured by vacuum forming in UPVC.
  • Available in black only.

300mm rafter roll - Product 1121 Single row of 300mm roll panel coverage suitable for:

Insulation depthMin roof pitch (deg.)
225mm40°
250mm45°

400mm rafter roll - Product 1171 Single row of 400mm roll panel coverage suitable for:

Insulation depthMin. roof pitch (deg.)
225mm32.5°
250mm37.5°
300mm48.5°

600mm rafter roll - Product 1131 Single row of 600mm roll panel coverage suitable for:

Insulation depthMin roof pitch (deg.)
225mm20°
250mm22.5°
300mm27.5°
400mm37.5°

800mm rafter roll - Product 1151 Single row of 800mm roll panel coverage suitable for:

Insulation depthMin roof pitch (deg.)
225mm17.5°
250mm20°
300mm22.5°
400mm30°

  • Unroll the ventilator along the rafters along the full length of the eaves and along both sides of the building to create a cross flow ventilation action.
  • Position centrally above the wall plate. This is the narrowest part of the roof where the roof insulation is most likely to constrict the airflow.
  • Push the corrugations down over the top of the rafters and secure using clout nails or staples.
  • Measure the overall length of the eaves to be ventilated and divide by 6m to determine the number of rolls of ventilator required.
